Airflow QuietAir Extractor Fan 120mm Motion Sensor/Timer
by Airflow Product Code: 77054 77054
Related products
Product Details
• Quiet from only 32 dB(A)
• Power consumption from only 10 watts
• Two speed options, 150 m3/hr and 170 m3/hr
• Motion sensor with overrun timer
• High efficiency impeller delivers up to 120m3/hr through long lengths of rigid ducting, including 90 degree bends
• Use in wet zone 1 when protected by an RCD and installed in accordance with latest IEE wiring regulations
• Integral flow straightener and back draught flap
• Low specific fan power for SAP assessments
• Clip-on cover for ease of cleaning
• Innovative room refresh option (interval timer) programmable for automatic long term routine ventilation
• Complies with latest 2010 Building Regulations Approved Document F
• Airflow 150/170 m3/hr, 41.6/47.2 l/sec
• Airflow 31Pa @ 120 m3/hr, 33.3 l/sec
• Axial high efficiency impeller
• Long life ball-bearing motor with 40,000 hours life
• Wall/ceiling mounting
• Sound pressure 32/36 dB(A) @ 3m
• Fixed run-on timer 15 minutes
• Power 10/13 watts
• Low SFP (Specific fan power) 0.24 w/l/s
• Voltage - 230/1/50-60Hz
• Rating IP45
• Max. ambient temperature 40 degree
Technical Specification
Certification | Building Reg Part F |
Material | ABS |
Type | Fans |
Power source | |
Mains or Battery | Mains |
Brand | Airflow |
Manufacturer ID | 9041500 |
Range Name | QuietAir |
Colour | White |
Depth (mm) | 155mm |
Width (mm) | 176mm |
IP Rating | IP45 |
Voltage | 230V |
Wattage | 13W |
Sound volume | 32dB |
Max. Flow Rate | 47 L/s |
Finish | Gloss |
Fitted Depth | 39mm |
Extractor Fan Shape | Square |
